Features of two pot parallel sterilization pot:

1. Uniform flow exchange mode, uniform temperature, no dead angle

The slow and orderly flow of water in the sterilization tank ensures the uniform heat distribution at any point in the sterilization pot from heating, heat preservation to cooling, so that the packaged food in different positions in the tray can be sterilized evenly, eliminating the dead corner of sterilization, and making the product's shelf life more stable and long.

2. High temperature and short time sterilization

This machine adopts double tank hot water circulation for sterilization. In the sterilization mode, the hot water is heated to the required temperature first, so as to shorten the sterilization time and improve the work efficiency.

3. High sterilization precision

The machine adopts exquisite technology, using hot water circulation, immersion sterilization, sterilization process of temperature, pressure, sterilization time automatic control.

4. Energy saving

The working medium in the sterilization process of the machine can be recycled, which saves energy, time, manpower and material consumption, and reduces the production cost.

5. Technical requirements

a. The equipment is manufactured, inspected and accepted in accordance with steel pressure vessels (GB 150-1998), and subject to the supervision of safety technology supervision regulation for pressure vessels.

b. Arc welding is adopted for welding. The welding procedure is in accordance with JB / t4709-2000. The welding rod grade of manual arc welding is A102 between stainless steel, A302 between carbon steel and stainless steel, and j426 between carbon steel. The automatic welding adopts h0cr21n10 and flux hj260.

c. The type and size of welding joint shall be in accordance with hg20583-1998 except as indicated in the drawing. The size of fillet weld leg shall be in accordance with the thickness of thin plate, and the welding of flange shall be in accordance with relevant flange standards.

d. The A and B welded joints on the vessel shall be subject to radiographic inspection, and the inspection length shall not be less than 20% of the length of each welded joint and shall not be less than 250mm. The results shall meet the requirements of grade III in JB / t47302-2005.

e. After the equipment is manufactured, the water test shall be conducted at the pressure of 0.44Mpa, and the chloride ion content in the water shall not be greater than 25ppm. This equipment is a new product developed by the extension of double-layer sterilization kettle. Its sterilization effect is the same as that of double-layer sterilization kettle, and its output is doubled.

The hot water for sterilization can be recycled between two sterilization kettles, and the user can greatly reduce the investment cost.
